Santa Cruz Megatower Carbon C - GX AXS Kit

Buy Detail About Spec Geometry More

Santa Cruz Megatower Carbon C - GX AXS Kit
Santa Cruz Megatower Carbon C - GX AXS Kit

Choose Your Build Options

Your Selected Build:

Regular price
£6,999.00
Sale price
  £6,999.00

Tax included. Shipping calculated at checkout.
Please Note: Bikes are built to order. During busy periods lead times may be several weeks.

Cycle to Work

Save between 30% - 47% with a Cycle to Work voucher. Click to Learn More...

Ride It With

Up Close...



A downhill bike that goes everywhere

Seriously. The Megatower’s big wheels, long-travel and tough carbon fiber chassis delivers the high-speed security traits of a downhill bike. Yet the relatively steep seat angle and size-specific geo maintain the Mega’s mega pedaling ability, elevating its reputation as the perfect choice for big gravity rides and DH park laps.

Set on a 29'er but think the Mega might be too much bike? : Check out the Hightower
Wanting all the travel, but with the playfulness of 27.5 inch wheels? : Check out the Nomad

Santa Cruz Megatower Features

  • Fork Travel : 170mm
  • Fork Compatibility : 170mm-180mm
  • Frame Travel : 165mm
  • Shock Size : 230x62.5
  • ICSG-05 Tabs : Yes
  • Brake Mounts : 200mm PM
  • Headset : Integrated (IS41/52)
  • Seatpost Diameter : 31.6mm
  • Seat Clamp Diameter : 36.4mm
  • BB Shell : 73mm Threaded
  • Max Tyre Size : 2.5"
  • Max Chaingring Size : 36t
  • Shock Mounting Bushing Front : 30x8
  • Shock Mounting Bushing Rear : 30x8
  • Derailleur Hanger : Santa Cruz (SRAM) UDH

Santa Cruz Megatower Carbon C - GX AXS Kit

Fork

Shock

Rear Derailleur

Shifter

Crankset

Cassette

Chain

Brakes

Rotors

Handlebars

Stem

Grips

Headset

Seatpost

Saddle

Front Tyre

Rear Tyre

Front Hub

Rear Hub

Rims

Spokes

Please Note: Whilst we do our best to keep this information accurate, due to the availability of components some parts listed here may be swapped in order to avoid lengthy delays.

Geometry

geoDiagram-wheelbase geoDiagram-topTubeLength geoDiagram-standOverHeight geoDiagram-stack geoDiagram-seatTubeAngle geoDiagram-seatTubeLength geoDiagram-reach geoDiagram-headTubeAngle geoDiagram-frontCenter geoDiagram-headTubeLength geoDiagram-chainStayLength geoDiagram-bbDrop geoDiagram-bbHeight geoDiagram
S M L XL XXL
Rider Height 5'2"+ 5'5"+ 5'9"+ 6'0"+ 6'4"+
Reach 430mm 455mm 475mm 495mm 520mm
Stack 616mm 625mm 638mm 656mm 670mm
Head Tube Angle 63.8° 63.8° 63.8° 63.8° 63.8°
Seat Tube Length 380mm 405mm 430mm 460mm 500mm
Front Center 770mm 799mm 826mm 855mm 886mm
BB Height 346mm 346mm 346mm 346mm 346mm
BB Drop 27mm 27mm 27mm 27mm 27mm
Wheelbase 1206mm 1236mm 1266mm 1298mm 1333mm
Chainstay Length 436mm 437mm 440mm 443mm 447mm
Head Tube Length 90mm 100mm 115mm 135mm 150mm
Top Tube Length 570mm 594mm 613mm 637mm 666mm
Seat Tube Angle 77.2° 77.4° 77.8° 77.8° 77.8°
Standover Height 709mm 716mm 723mm 722mm 724mm
Eye to Eye Length 230mm 230mm 230mm 230mm 230mm
S M L XL XXL
Rider Height 5'2"+ 5'5"+ 5'9"+ 6'0"+ 6'4"+
Reach 427mm 452mm 472mm 492mm 517mm
Stack 618mm 627mm 640mm 658mm 672mm
Head Tube Angle 63.5° 63.5° 63.5° 63.5° 63.5°
Seat Tube Length 380mm 405mm 430mm 460mm 500mm
Front Center 770mm 799mm 826mm 855mm 886mm
BB Height 343mm 343mm 343mm 343mm 343mm
BB Drop 30mm 30mm 30mm 30mm 30mm
Wheelbase 1206mm 1237mm 1266mm 1298mm 1334mm
Chainstay Length 437mm 438mm 441mm 444mm 448mm
Head Tube Length 90mm 100mm 115mm 135mm 150mm
Top Tube Length 570mm 595mm 613mm 638mm 667mm
Seat Tube Angle 77° 77.2° 77.5° 77.5° 77.5°
Standover Height 705mm 712mm 718mm 717mm 720mm
Eye to Eye Length 230mm 230mm 230mm 230mm 230mm
